Reversible ratchet combination wrench 8-32 MM TENGTOOLS

Reversible ratchet combination wrenches 8-32 MM TENGTOOLS. 15-degree inclination. Combination of open-end/box-end and bi-hexagonal ratchet. Same dimensions on both ends. Chrome vanadium. Matte finish.

FEATURES

A ratchet ring and an open-end wrench combined with the same size at each end

15° offset for easier use on flat surfaces

TengTools hip grip design at the end of the ring for contact with the flat side of the fastener

72-tooth ratchet wrenches that provide a 5° increment between clicks

Reversible ratchet mechanism with a flip reverse lever

Ideal for quickly tightening and loosening fasteners.

Satin chrome vanadium finish

Designed and manufactured according to DIN ISO 1711-1 and DIN 3113A

TECHNICAL DATA

USES AND APPLICATIONS

Workshop/Construction Equipment

NORMATIVE

The DIN 3113A standard specifically focuses on metric combination wrenches that have a fixed jaw on one side and a bent star (ring) jaw on the other. This specification details the precise dimensions of both jaws (the fixed and the bent), the angle of the bent ring (generally 15° to facilitate access to fasteners in tight spaces), and the nominal length of the wrench. The "A" in the designation refers to this particular design of combination wrench with the bent star jaw. By complying with DIN 3113A, it ensures that the wrench will have the correct measurements to work with metric screws and nuts, as well as providing the expected functionality and ergonomics to reach hard-to-access areas, all while maintaining the quality and performance standards defined by other complementary standards such as ISO 1711-1.
