Mobile anchor point with wheels for metal beam and resistance 12 kN GRAB N ROLL KRATOS SAFETY

The mobile anchor point GRAB'N'ROLL from Kratos Safety is a versatile and safe solution for working at heights that require mobility. Designed to be fixed to metal beams, this anchor allows workers to move easily and safely along the structure, thanks to its wheel system. With a strength of 12 kN, it ensures optimal protection in case of a fall, complying with the most demanding safety regulations.

FEATURES

• GRAB'N'ROLL - Mobile anchor point with wheels for metal beams
• Attachment with forged steel ring (inner diameter of 55 mm), tied to the bar.
• Materials: Aluminum and stainless steel. D-ring in forged steel.
• Dimensions: Thanks to its adjustable brackets, it can be installed on beams from 80 to 250 mm wide.
• Tensile strength: 23 kN.
• Compliance: EN795:2012 Type B.
• Static strength according to EN795:2012 Type B: 12 kN.
• HS Code: 8308 10 10

USAGE

There is no good fall protection system without a good anchor point. Regardless of the type of intervention to be carried out, whether temporary or regular, it is essential to choose the anchor point carefully and to ensure that the supporting structure (building, metal structure, post) is sufficiently strong.

HOW TO CHOOSE

The anchor point is undoubtedly the most delicate element of a fall protection system that must be chosen to ensure optimal safety. When selecting the anchor point, it is necessary to first determine where to install it. To do this, the following aspects must be considered: static strength of the anchor point: > 10 kN installation height: sufficiently high in relation to the first potential obstacle in case of a fall (see fall factor diagram) situation: vertically from the workstation to avoid risks associated with the pendulum effect (see pendulum effect diagram)

VIDEO

STANDARDS

- EN 795:2012 Type B: refers to anchor systems for fall protection in work at heights. Specifically, Type B focuses on anchor devices that are installed on structures and can be used by one or more workers to secure their harness and prevent falls.

APPLICATIONS

• For metal beams.
