Intermediate post of horizontal life line KS-Line for steel sheet roof and breaking strength 15 kN KRATOS SAFETY

The KS-Line Intermediate Post from Kratos Safety, with a breaking strength of 15 kN, is an essential component for the installation of horizontal lifelines on steel sheet roofs. Designed to meet the needs of each project, this intermediate post ensures an even distribution of loads along the lifeline, providing maximum safety for workers.

Made of stainless steel 316, it offers exceptional resistance to corrosion and atmospheric agents, ensuring a long service life. Its installation is simple and quick, thanks to its fastening system using watertight rivets and EPDM bands.

FEATURES

• Fastening with 16 watertight rivets on steel sheet roofing.
• Mounting plate with various holes to adapt to different dimensions (see spacing measurements in the technical data sheet).
• Supplied with EPDM bands to ensure watertightness.
• Allows for the attachment of the intermediate piece FA 60 204 00.
• Minimum thickness of the steel sheet: 0.5 mm.
• Material: Stainless steel 316.
• Weight: 3.19 kg.
• Breaking strength > 15 kN.

TECHNICAL DATA

• HS: 73269098

APPLICATIONS

• Horizontal lifelines on roofs
• Even distribution of loads
• Industries with work at height
