Motorized shear MTBS 1255-40 E METALLKRAFT

Motorized shear MTBS 1255-40 E METALLKRAFT. The MTBS 1255-40 E motorized shear from METALLKRAFT cuts steel and non-ferrous metals. Its robust construction and high-quality blade ensure precision and efficiency.

FEATURES

• Suitable for cutting steel and non-ferrous metals.
• Welded steel construction, sturdy and stress-free
• High-quality blade
• Sheet support arms for large parts
• Cutting line illumination and slots in the upper cover plate for optimal visibility of the cutting edge to cut on the marking line
• Manual rear stop of 630 mm with micrometric precision adjustment
• Light barrier for the rear stop area
• The pedal leaves both hands free for material feeding.

TECHNICAL SPECIFICATIONS

Working width 1250 millimeters

Cutting performance with material tensile strength of 400 N/mm² 4 millimeters

Cutting performance with material tensile strength of 700 N/mm² 2

Explanation of cutting performance Values for stainless steel (700 N/mm²) only achievable with optional blade set

Number of sheet support arms 2 pieces

Adjustment range of the rear stop up to 630 millimeters

Cutting angle 2.4 °

Maximum strokes at full cutting length 30 rpm

PU 1

Dimensions and weights

Approximate length 1712 millimeters

Approximate width/depth 1605 millimeters

Approximate height 1190 millimeters

Approximate weight. 1185 kilograms

Electrical data

Drive motor power 4.0 kW

Connection voltage 400 volts

Network frequency 50 Hz

COMPONENTS/PACKAGING

Unit of measure: piece

Packaging unit: 1

• Metal sheet support arms
• Lateral stop
• Manual rear stop
• Foot control

EQUIPMENT

Number of sheet support arms 2 pieces

FOR WHAT TYPE OF WORK IS IT SUITABLE

The MTBS 1255-40 E METALLKRAFT motorized shear is suitable for:

• Cutting steel and non-ferrous metals
• Industry
• Craftsmanship
