Inverter Welder Tig Technology Tig 230 DC + ACC TELWIN

TIG Inverter Welder Technology Tig 230 DC + ACC TELWIN. TIG inverter welder (high frequency HF and LIFT ignition), PULSED TIG - easy pulsed and MMA in direct current (DC), controlled by a microprocessor. Suitable for a variety of materials such as steel, stainless steel, titanium, copper, nickel, and their alloys. INCLUDES TIG WELDING KIT.

FEATURES

• TIG inverter welder (HF or LIFT ignition), PULSED TIG and MMA in direct current (DC), 220A. With TIG welding accessories.
• Operation in PULSE and EASY PULSE modes.
• Advanced THINSPOT function for easy, precise, and quick spot welding in TIG for thin sheets.
• VRD device for increased safety in welding operations in humid environments.
• Prepared for remote control.
• 20A network fuse programmable to 16A.

TECHNICAL DATA

CODE 852055

NETWORK FREQUENCY 50 / 60 Hz

MAX CURRENT 220 @ 30 % A

MAX OPEN CIRCUIT VOLTAGE 95 V

CURRENT ABSORBED AT 60% 26 A

POWER ABSORBED AT 60% 4.1 kW

POWER FACTOR 0.7

PROTECTION DEGREE IP23

WEIGHT 14.75 kg

SINGLE-PHASE NETWORK VOLTAGE 230 V

REGULATION RANGE 10 - 220 A

DC INPUT CURRENT 125 A

MAX ABSORBED CURRENT 36 A

MAX ABSORBED POWER 6 kW

EFFICIENCY 86 %

USABLE ELECTRODES IN DC 1.6 - 4 mm

DIMENSIONS 43 x 17.6 x 34 cm

NORMATIVES

TIG inverter welder (HF or LIFT ignition), PULSED TIG and MMA in direct current (DC), 220A

SINGLE-PHASE NETWORK VOLTAGE 230 V

Prepared for remote control.

E: The product complies with the standards and regulations of the Eurasian Economic Union (EAEU)

EAC: The product meets the safety, health, and environmental protection requirements of the European Union (EU)

FOR WHAT TYPE OF WORK IS IT SUITABLE

The TIG Inverter Welder Technology Tig 230 DC + ACC TELWIN is suitable for:

• Workshops
• Metallurgy
• DIY
• Industry
• Construction
