TIG Welder TIG 190 DC Lift TELWIN

TIG Welder Technique Tig 190 DC Lift TELWIN. Inverter TIG welder (LIFT ignition) and MMA in direct current (DC). Suitable for a variety of materials such as steel, stainless steel, titanium, copper, nickel, and their alloys.

The VRD (Voltage Reduction Device) reduces the output voltage to a safe level when the welder is on but not in welding conditions. This device ensures the safety of the operator, who can come into contact with the electrode without risks until welding operations resume (for use in wet environments, such as mines or shipyards, etc.).

FEATURES

• Inverter welder for MMA and TIG (LIFT ignition) in direct current (DC) 170A with LCD display. Comes with accessories for electrode welding and a plastic case.
• MMA welding with arc-force regulation and hot-start devices; welds rutile, basic, stainless, and cast electrodes up to Ø 4mm.
• Equipped with a display for visualizing the configured welding current.
• Thermostatic protection, voltage rise and fall, current rise. Compatible for use with a generator (230V +/- 15%).
• VRD device for added safety in welding operations in wet environments.
• Lightweight and compact. Easily transportable. Low consumption thanks to inverter technology.

TECHNICAL DATA

CODE 816220

NETWORK FREQUENCY 50 / 60 Hz

%USE (A 20°C) 88% @ 150A

DC CURRENT 110 A

MAX OPEN CIRCUIT VOLTAGE 14 V

CURRENT ABSORBED AT 60% 17 A

POWER ABSORBED AT 60% 2.6 kW

EFFICIENCY 86 %

USABLE ELECTRODES IN DC 1.6 - 4 mm

DIMENSIONS 38 x 42 x 17 cm

SINGLE PHASE NETWORK VOLTAGE 230 V

REGULATION RANGE 10 - 170 A

MAX CURRENT 160 @ 20 % A

MAX OPEN CIRCUIT VOLTAGE 78 V

MAX ABSORBED CURRENT 29 A

MAX ABSORBED POWER 4.4 kW

MINIMUM GENERATOR POWER 6 kW

POWER FACTOR 0.7

PROTECTION DEGREE IP23

WEIGHT 9.4 kg

NORMS

Inverter welder for MMA and TIG (LIFT ignition) in direct current (DC) 170A with LCD display.

SINGLE PHASE NETWORK VOLTAGE 230 V

Compatible for use with a generator (230V +/- 15%).

CE: The product complies with the standards and regulations of the Eurasian Economic Union (EAEU)

EAC: The product meets the safety, health, and environmental protection requirements of the European Union (EU)

WHAT TYPE OF WORK IS IT SUITABLE FOR

The TIG Welder Technique Tig 190 DC Lift TELWIN is suitable for:

• Workshops
• Metallurgy
• DIY
• Industry
• Construction
