Solid table for manual welding with integrated waste drawer KEMPER

Solid table for manual welding with integrated waste drawer. KEMPER welding tables are the ideal solution for manually assembling small metal parts. A slag drawer allows for easy cleaning of the table, and through a pipe, the table connects to the extraction system. Additionally, extraction can also be done through an optional fan.

FEATURES

• Robust support grid
• Integrated slag drawer
• Welded steel sheet construction ergonomically adapted
• Connection to a filtration system or a fan is possible

VARIANTS

Various sizes

TECHNICAL DATA

• Width: 800 mm
• Height: 850 mm
• Dimensions (H x W x D): 1,000 x 800 x 850 mm

Additional information

• Extraction points: 160 mm
• Recommended filtration system: 6420

SUMMARY/ APPLICATIONS

• Processing small metal parts by hand

BENEFITS

• Safe work thanks to the robust material layer
• Easy cleaning thanks to the integrated slag drawer
• Pleasant work due to the ergonomically adapted steel sheet construction
