Mixed concrete metal anchor with 70 cm tape SAFETOP

Mixed concrete metal anchor with 70 cm tape SAFETOP. The mixed concrete metal anchor with 70 cm tape SAFETOP is a mechanical fastening device designed to be installed in reinforced concrete structures, whether on the ceiling or wall. Certified according to the EN 795 Type A standard, it guarantees user safety with a Fall Factor of 0, making it ideal for areas such as material reception platforms and elevator doors. Available in standard lengths of 70, 150, and 250 centimeters, it is compatible with retractables (EN-360) and vertical anchor lines (EN-353.2), offering versatility in various applications.

FEATURES

• Mechanical fastening anchor.
• Anchoring device to be installed with MECHANICAL PLUG in reinforced concrete structures.
• Installation on ceiling or wall.
• Certified according to EN 795 Type A standard, including the fastening.
• For areas such as material reception platforms, elevator doors...
• Secures the user with a Fall Factor of 0.
• Can be installed on both "wall" and "ceiling".
• Three standard lengths of 70, 150, and 250 centimeters.
• Suitable for the fastening of retractables (EN-360), "vertical anchor lines" (EN-353.2), among other applications.
• Fast and reliable process when performed on expansive mechanical plugs.
• Designed for 1 single user.

BENEFITS

Fast and reliable process when performed on expansive mechanical plugs.

APPLICATIONS

The mixed concrete metal anchor with 70 cm tape SAFETOP is suitable for:

• Overhanging platforms
• Large dimension skids for installations
• Elevator door openings

TECHNICAL DATA

• MATERIALS: Appendix with a screw eye on an expansive metal plug that secures the Anchoring Device to the structural element.
• STANDARDS: EN 795 Class A (Anchoring device)

REGULATIONS

- EN795 Class A: The EN 795 standard establishes safety requirements for anchoring devices used in fall protection systems. Class A refers to fixed anchors, which must be installed in a permanent location and designed to withstand specific loads, ensuring user safety in work at height.

LIFETIME

Maximum lifespan of 24 months from its first installation and in any case 48 months from its manufacturing date. Single use only.

Inspections: Inspect periodically, depending on the use of the anchor, up to once a week if it is intensive, checking the condition of the tape in contact with the eye inside the loop that houses it.

**This device may become damaged when exposed to strong and constant winds. In such cases, check the condition of the tape at least every 2 days.
