Fall protection harness with extension straps IRUDEK EXPERT 1 PRO

Fall protection harness with IRUDEK EXPERT 1 PRO extension straps. Includes dorsal and frontal fall protection ring.

The fall protection harness is a basic component of the fall protection system in accordance with Standard EN 363:2018.

FEATURES

• Total protection: Dorsal and sternal rings with dorsal extension.
• Quick adjustment: K-EASY automatic buckles made of galvanized steel.
• Superior comfort: Padded back and shoulders with RIPSTOP fabric.
• Perfect ergonomics: Adjustable straps for height and legs.
• Guaranteed stability: ANTISLIP system for greater grip.
• Traceability and control: Integrated NFC Ready chip.
• Meets the highest standards, ideal for demanding environments.
• Sizes: S-M, L-XL

TECHNICAL DATA

• Weight: 1570g | 1620g
• Usage capacity: 140 Kg
• Resistance > 15 kN
• Antislip System: Yes
• Automatic buckles: Yes
• Service life (years): 10 years of use + 2 of storage
• Strap width: 45 mm

PACKAGING DATA

• Units/box: 1

MATERIALS

• Strap: Polyester
• Ring: Steel
• Protector: Polyamide

SIZE GUIDE

A

S-M: 55-60

L-XL: 55-70

C

S-M: 45-80

L-XL: 45-100

* Measurements expressed in centimeters

STANDARDS/REGULATIONS

EN 361

USAGE LIMITATIONS

The equipment must be assigned individually to a person.

- It is recommended that the anchorage point where the fall protection system will be fixed is above the user. The anchorage point must have a minimum static resistance of 12 kN (metal) or 18 kN (textile) and must comply with the requirements of Standard EN 795:1996 / EN 795:2012.

- Personal protective equipment should not be used by those individuals whose health status may affect the safety of the user under normal use conditions or in case of emergency.

- Personal protective equipment should only be used by a trained and competent person in its safe use.

WARNING

- A fall protection harness is the only acceptable body restraint device that can be used in a fall protection system.

- The fall protection system must only be connected to the connection points of the harness that carry an identification with the capital letter “A”. The identification “A/2” indicates that it is necessary to connect two connection points with the same identification at the same time. It is prohibited to connect the protection system to a single connection point identified with “A/2”.

- In harnesses with an integrated belt, the connection to equipment for positioning work must only be made to the lateral anchorage rings of the belt.

- The connection to the anchorage point and other equipment must be made through carabiners in accordance with EN362:2004.

- For use with fall protection EN 353-1:2014+A1:2017, EN 353-2:2002, it is recommended to connect the equipment to the frontal anchorage point of the harness. For use with energy absorbers EN 355 or with fall protection EN 360, it is recommended to connect the equipment to the dorsal anchorage point of the harness.

- Before each use of the personal protective equipment, it must be carefully inspected to ensure it is in usable condition and functioning correctly.

- During the pre-use check, it is necessary to carefully inspect all elements of the equipment to verify that they do not show signs of deterioration, excessive wear, corrosion, abrasions, UV radiation degradation, cuts, or incorrect use. Pay special attention to the straps, seams, anchorage rings, buckles, and adjustment elements.
