Internal Micrometer with LIMIT clock

Internal Micrometer with LIMIT Clock. The internal micrometer with LIMIT clock allows for precise measurements in holes and grooves. With interchangeable tips, a precision of ±15 μm, and a range of 10 mm to 250 mm, it is ideal for industrial applications.

FEATURES

• For precise measurements in holes and grooves.
• Equipped with interchangeable measuring tips and spacers for different dimensions.
• The indicator automatically centers itself using a spring support and features a measuring tip coated with tungsten carbide.
• Includes a dial gauge.
• The precision is ±15 μm, plus the gauge's accuracy according to DIN 878.
• The bottom of the hole can be measured from the bottom.

TECHNICAL DATA

Measuring range: 10-18 mm  /  18-35 mm  /  35-50 mm  /  50-160 mm  /  160-250 mm

Number of measuring tips: 9 units  /  7 units  /  4 units  /  12 units  /  5 units

Bottom hole: 7 mm  /  7.5 mm  /  10 mm  /  15 mm

Measuring depth: 100 mm  /  125 mm  /  150 mm  /  150 mm  /  400 mm

Inaccuracy: 0.01 mm

ETIM class code: EC003591

FOR WHAT TYPE OF WORK IS IT SUITABLE

The Internal Micrometer with LIMIT Clock is suitable for:

• Mechanical engineering
• Metallurgy
• Automotive industry
• Verification of dimensions in mechanical components
• Measurement of pipes and other elements
• Measurement of hole diameters
